ZONESUN ZS-TB100SW Semi Auto Labeling Machine for Round Bottles
The ZONESUN ZS-TB100SW offers precise single-side and double-side labeling for round bottles with wider format support. Compact and semi-automatic, it’s ideal for small production lines in food, cosmetic, and chemical industries. The machine can be integrated with a date coder to print batch numbers or production dates, improving traceability and efficiency. With adjustable labeling settings and strong compatibility across container sizes, it’s built for flexibility and accuracy.
Parameter Details
Machine Model ZS-TB100SW
Main Feature Wider Labeling Capability
Power Supply 110V/220V, 50–60Hz
Working Speed 15–35 pcs/min
Labeling Accuracy ±1 mm
Air Pressure 0.4–0.6 MPa
Label Outputting Direction Right
Labeling Object Diameter φ10–150 mm
Labeling Object Height ≤380 mm
Suitable Label Size ≤200 mm (Width)
Label Roll Outer Diameter φ220 mm
Label Roll Inner Diameter φ75 mm
Air Compressor Connector OD 8 mm
Machine Size Approx. 415 mm × 420 mm × 690 mm
Package Size Approx. 480 mm × 575 mm × 685 mm
Net/Gross Weight Approx. 32 kg / 42 kg
Original: $1,098.00
-70%$1,098.00
$329.40More Images
ZONESUN ZS-TB100SW Semi Auto Labeling Machine for Round Bottles
The ZONESUN ZS-TB100SW offers precise single-side and double-side labeling for round bottles with wider format support. Compact and semi-automatic, it’s ideal for small production lines in food, cosmetic, and chemical industries. The machine can be integrated with a date coder to print batch numbers or production dates, improving traceability and efficiency. With adjustable labeling settings and strong compatibility across container sizes, it’s built for flexibility and accuracy.
Parameter Details
Machine Model ZS-TB100SW
Main Feature Wider Labeling Capability
Power Supply 110V/220V, 50–60Hz
Working Speed 15–35 pcs/min
Labeling Accuracy ±1 mm
Air Pressure 0.4–0.6 MPa
Label Outputting Direction Right
Labeling Object Diameter φ10–150 mm
Labeling Object Height ≤380 mm
Suitable Label Size ≤200 mm (Width)
Label Roll Outer Diameter φ220 mm
Label Roll Inner Diameter φ75 mm
Air Compressor Connector OD 8 mm
Machine Size Approx. 415 mm × 420 mm × 690 mm
Package Size Approx. 480 mm × 575 mm × 685 mm
Net/Gross Weight Approx. 32 kg / 42 kg
Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
The ZONESUN ZS-TB100SW offers precise single-side and double-side labeling for round bottles with wider format support. Compact and semi-automatic, it’s ideal for small production lines in food, cosmetic, and chemical industries. The machine can be integrated with a date coder to print batch numbers or production dates, improving traceability and efficiency. With adjustable labeling settings and strong compatibility across container sizes, it’s built for flexibility and accuracy.
Parameter Details
Machine Model ZS-TB100SW
Main Feature Wider Labeling Capability
Power Supply 110V/220V, 50–60Hz
Working Speed 15–35 pcs/min
Labeling Accuracy ±1 mm
Air Pressure 0.4–0.6 MPa
Label Outputting Direction Right
Labeling Object Diameter φ10–150 mm
Labeling Object Height ≤380 mm
Suitable Label Size ≤200 mm (Width)
Label Roll Outer Diameter φ220 mm
Label Roll Inner Diameter φ75 mm
Air Compressor Connector OD 8 mm
Machine Size Approx. 415 mm × 420 mm × 690 mm
Package Size Approx. 480 mm × 575 mm × 685 mm
Net/Gross Weight Approx. 32 kg / 42 kg
